Research - International Journal of Medical Research & Health Sciences ( 2022) Volume 11, Issue 5
Morphometric Study of Left Coronary Artery in Human Adult Heart
GA Jos Hemalatha1, K. Arumugam2* and J. Sreevidya32Department of Anatomy, Tirunelveli Medical College, Tirunelveli, India
3Department of Anatomy, Madras Medical College, Chennai, India
K. Arumugam, Department of Anatomy, Tirunelveli Medical College, Tirunelveli, India, Email: drkatut@gmail.com
Received: 03-Mar-2022, Manuscript No. ijmrhs-22-55976 ; Editor assigned: 09-Mar-2022, Pre QC No. ijmrhs-22-55976 (PQ); Reviewed: 03-May-2022, QC No. ijmrhs-22-55976 (Q); Revised: 10-May-2022, Manuscript No. ijmrhs-22-55976 (R); Published: 31-May-2022
Abstract
Aim: To study the number, level of left coronary Ostia, branching pattern of the left coronary artery, and the length of the stem of the left coronary artery. Materials and Methods: This study is conducted on 5 cadaver hearts in the department of Anatomy of college. Results: In the present study about 92% of specimens have single Ostia and 8% of specimens have double Ostia. About 64% of heart coronary Ostia are below the sino-tubular junction and about 36% are above the sino-tubular junction. Left coronary artery bifurcates in 84% of specimens and 16% of specimens trifurcate. The length of the stem of the left coronary artery is between 12.45 mm to 25.2 mm and the external diameter of the left coronary artery is between 2.39 mm to 6.58 mm. Conclusion: Studying the variations of the coronary artery is helpful for Interventional Cardiologists and Radiologists to interrupt the various diagnostic and therapeutic procedures.
Keywords
Ostia, Sino-tubular junction, Left coronary artery
Introduction
In the normal heart, oxygenated blood is supplied by two coronary arteries that arise from the ascending aorta. The Left coronary artery originates from the left posterior aortic sinus and runs towards the left, under the left auricle. After a short course, it divides into two vessels, the left anterior descending artery, and the circumflex artery. The left coronary artery trunk presents a wide variability in its morphological expression with regards to its length, level of origin, and several terminal branches. There is a correlation between the length of the main left coronary artery and atherosclerosis present in its branches or the presence of a complete left bundle branch block. Approximately a third of worldwide deaths are caused by ischemic or coronary heart disease, suggesting that greater attention is needed to study the coronary diameter and myocardial vasculature. Thus, the knowledge of such variations is important for the evaluation of percutaneous coronary artery interventions, coronary artery surgeries, or prosthetic valve replacements, and last but not the least, for its academic value among upcoming clinicians.
Objectives of the Study
To study about
• Number of left coronary ostium
• Level of left coronary ostium
• Branching pattern of left coronary artery
• Length of left coronary artery
Materials and Methods
The present study was conducted on 25 adult heart specimens that were used during routine dissection for MBBS students in the Department of Anatomy at Tirunelveli Medical College. Twenty-five specimens of the heart were collected by cutting ribs and sterna and opening of thoracic cavities of the cadavers. The great vessels, ascending aortas, and pulmonary trunks were ligated by using threads at two places and they were then cut in between the two ligatures. The parietal pericardium was incised and the heart, along with the proximal part of the great vessels, was taken out of the pericardial cavity. Then, the aorta and the pulmonary trunk were excised about 2 cm above the supravalvular ridge. All the collected samples were kept in 10% formalin. After a gradual separation and retraction of the myocardial fascicule, the left coronary artery was exposed. The length of the main trunk was measured by using a vernier caliper and the branching patterns were noted. The ascending aorta was cut longitudinally (near the right posterior non-coronary sinus) to check the position, number, and level of the left coronary ostium.
Results
The following observations were seen in our study.
The Number of Ostia
Among the 25 specimens collected, we observed that only two specimens had two coronary Ostia noted at the left posterior aortic cusp. The rest of the specimens had only one coronary ostium in the left posterior aortic cups.
Level of Ostia
Among the 25 specimens, we observed that in 16 specimen’s ostium is located below the sino-tubular junction, and the remaining 9 specimens it is located above the sino-tubular junction (Figure 1 and Figure 2).
Figure 1. Left coronary ostium below the level of the sino-tubular junction
Figure 2. Left coronary ostium above the sino-tubular junction
Branching Pattern
In this study we observed about 21 specimens there was the bifurcation of the left coronary artery and the remaining 4 specimens observed that there was trifurcation of the left coronary artery (Figure 3 and Figure 4).
Figure 3. Left coronary artery-Bifurcation
Length of Left Coronary Artery
From the findings given in Table 1, the length of the stem of the left coronary artery is between 12.45 mm and 25.2 mm.
| No of specimen | Length of the stem of left coronary artery (mm) | External diameter of left coronary artery (mm) |
|---|---|---|
| 1 | 15.79 | 4.29 |
| 2 | 18.41 | 4.71 |
| 3 | 14.98 | 2.82 |
| 4 | 13.45 | 3.74 |
| 5 | 13.54 | 3.5 |
| 6 | 13.23 | 2.39 |
| 7 | 14.26 | 5.72 |
| 8 | 15.23 | 3.6 |
| 9 | 14.51 | 4.34 |
| 10 | 25.2 | 6.45 |
| 11 | 12.1 | 6.58 |
| 12 | 15.2 | 4.5 |
| 13 | 14.75 | 5.5 |
| 14 | 17.58 | 3.4 |
| 15 | 18.5 | 3.45 |
| 16 | 19.67 | 4.25 |
| 17 | 20.01 | 4.15 |
| 18 | 18.78 | 3.87 |
| 19 | 13.45 | 3.94 |
| 20 | 12.45 | 3.87 |
| 21 | 17.15 | 3.5 |
| 22 | 16.18 | 4.01 |
| 23 | 15.75 | 4.25 |
| 24 | 14.01 | 4.45 |
| 25 | 15.07 | 4.5 |
Discussion
Number of Ostia
In most of the studies, the double Ostia is about 2% to 2.5%. But in our study, the double Ostia is somewhat higher about 8% (Table 2).
| References | Number of Ostia | |
|---|---|---|
| 1 | 2 | |
| Dakane, et al. [1] | 98% | 2% |
| Nasi, et al. [2] | 97.50% | 2.50% |
| Present study | 92% | 8% |
Level of Ostia
The level of Ostia is below the level of sino-tubular junction in all the (100%) specimens reported in the Dakane, et al. study [1].
But Cavaleanti, et al. study mentioned about 40% of specimens the level of Ostia was above the sino-tubular junction, in 42% it was below the sino-tubular junction, and in 18% it was at the level of the sino-tubular junction [3].
In Alam’s study, 98% of specimens reported the coronary ostium is above the sino- tubular junction [4].
Our study didn’t match with the above studies and no specimens had the Ostia is at the level of the sino-tubular junction and in 64% of specimens the level of Ostia is below the sino-tubular junction (Table 3).
| References | Level of Ostia | ||
|---|---|---|---|
| Below Sino-tubular junction | At Sino-tubular junction | Above Sino-tubular junction | |
| Ray, et al. [5] | 65% | Nil | 35% |
| Cavaleanti, et al. [3] | 42% | 18% | 40% |
| Doube, et al. [6] | 79% | 17.20% | 3% |
| Kumar, et al. [7] | 78% | 15% | 7% |
| Bhele, et al. [8] | 78% | 16% | 4% |
| Sultan Ruma Alam [4] | 2% | Nil | 98% |
| Dakane, et al. [1] | 100% | Nil | Nil |
| Present study | 64% | Nil | 34% |
Branching Pattern
Our study findings are more or less similar to Anbusudar, et al. study [9]. In Ray, et al. and Doube, et al. studies reported tetrafurcation in 2% and 7.8% specimens [5,6]. But in our study tertafurcation of the left coronary artery is not reported (Table 4).
| References | Branching pattern | ||
|---|---|---|---|
| Bifurcation | Trifurcation | Tetrafurcation | |
| Cavalcanti, et al. [3] | 60% | 38.18% | Nil |
| Ray, et al. [5] | 56% | 40% | 2% |
| Doube, et al. [6] | 54.70% | 35.90% | 7.80% |
| Bhele, et al. [8] | 70% | 24% | 6% |
| Sultan Ruma Alam [4] | 74% | 26% | Nil |
| Anbusudar, et al. [9] | 80% | 20% | Nil |
| Present study | 84% | 16% | Nil |
Length of Left Coronary Artery
Our present study didn’t match any studies and the length of the stem of the left coronary artery is between 12.45 mm to 25.2 mm (Table 5) [10].
| References | Average length of left coronary artery |
|---|---|
| Bhele, et al. [5] | 2 mm to 17 mm |
| Sultan Ruma Alam [6] | 5 mm to 20 mm |
| Present study | 12.45 m to 25.2 mm |
Conclusion
The knowledge of the branching pattern of the coronary artery is helpful for radiologists and Interventional cardiologists to perform various therapeutic and diagnostic procedures like coronary angiogram, coronary angioplasty, and bypass graft procedures. Knowledge of the number and position of coronary Ostia is mandatory for performing coronary artery catheterization. Proper knowledge of the anatomy of coronary arteries and their variations is useful for a successful outcome following treatment of coronary artery disease.
Declarations
Conflict of Interest
The author(s) declared no potential conflicts of interest with respect to the research, authorship, and/or publication of this article.
References
- Dakhane Prafulla, S., and R. Patil Tushar. "Study of coronary ostia in preserved human cadaveric heart specimens in western Maharashtra by dissection method." International Journal of Anatomy and Research, Vol. 6, No. 3.1, 2018, pp. 5400-04.
Google Scholar Crossref - Nasr, Ashraf Youssef, and Mohammad El Tahlawi. "Anatomical and radiological angiographic study of the coronary ostia in the adult human hearts and their clinical significance." Anatomy & Cell Biology, Vol. 51, No. 3, 2018, pp. 164-73.
Google Scholar Crossref - Cavalcanti, Jennecy Sales, Natalia Correa Vieira de Melo, and Renata Simoes de Vasconcelos. "Morphometric and topographic study of coronary ostia." Brazilian Archives of Cardiology, Vol. 81, 2003, pp. 359-62.
Google Scholar Crossref - Alam, Sultana Ruma. "Variations in the left coronary artery." Chattagram Maa-O-Shishu Hospital Medical College Journal, Vol. 16, No. 1, 2017, pp. 42-47.
Google Scholar Crossref - Roy, Sanchita, et al. "Morphometric study of left coronary artery trunk in adult human cadavers: A study on the eastern region population." Journal of Clinical and Diagnostic Research: JCDR, Vol. 8, No. 2, 2014, pp. 7-9.
Google Scholar Crossref - Dombe, Dattatray D., et al. "Clinically relevant morphometric analysis of left coronary artery." International Journal of Biological & Medical Research, Vol. 3, No. 1, 2012, pp. 1327-30.
Google Scholar - Kaur, Dalbir, et al. "Morphology and morphometry of coronary ostia in South Indian adult human cadaveric hearts." International Journal of Biological & Medical Research, Vol. 3, No. 3, 2012, pp. 2169-71.
Google Scholar - Bhele, Ashwini Vijay, et al. "A study of course, branches and variations of the coronary arteries in the human cadaveric heart." International Journal of Contemporary Medical Research, Vol. 4, No. 7, 2017, pp. 1533-37.
Google Scholar - Anbusudar, Kalai, and Dhivya Sengottuvel. "An anatomical study on branching pattern of coronary arteries: A cadaveric study." Indian Journal of Anatomy, Vol. 9, No. 1, 2020, pp. 23-26.
Google Scholar Crossref - Darvishi, Marzieh, and Ardeshir Moayeri. "Anatomical indicators of the heart and coronary arteries: An anthropometric study." Biomedical Research and Therapy, Vol. 7, No. 9, 2020, pp. 3977-84.
Google Scholar Crossref
